Project Network is a distributed model of work to be completed in a project. Such a model includes a hierarchy of interdependent work elements (processes, tasks, activities) sequenced and prioritized to identify and define total effort of the project. Project network is usually built and designed with help of hierarchical diagrams and charts (project network diagram).

Project network includes multiple sequences of activities that determine one or another work element such as phase or process. The key condition for project network to be effective is that every activity sequence should provide a finite and measurable result and should never contain any circular references. If an activity sequence contains a circular reference, then it creates a closed loop which causes an endless cycle.

Project network diagram creates a visual representation of project network including activity sequences. It shows established dependencies betweens project tasks and processes. Dependencies are displayed as two-way arrows. Project network diagram is helpful in defining, documenting, analyzing and improving project tasks and activities. It is also called project flowchart .


  • See all teams
  • See all use cases
  • See all integrations
  • See all features
  • Submit a Ticket
  • Help Center
  • Premium Support
  • Community Topics
  • Training Courses
  • Facilitated Services

What Is a Network Diagram in Project Management?

  • 1.  Project Management Basics
  • 2.  Project Management Methodologies
  • 3.  Project Management Life Cycle
  • 4.  Project Management Software
  • 5.  Team Collaboration Tips
  • 6.  Agile Methodology Basics
  • 7.  Agile Project Management Tools & Techniques
  • 8.  Project Management Frameworks
  • 9.  Resources
  • 10.  Glossary
  • Advanced Terminology
  • Methodologies
  • PM Software Features
  • Basic Terminology
  • Professional Development
  • Agile Project Management

What is a Network Diagram in Project Management?

Whether you’re a project manager or a project team member, you should familiarize yourself with network diagrams — also known as the project schedule network diagram. A project network diagram is an important tool because it helps teams visualize the activities that need to be completed over the duration of a project. It also gives crucial context like task duration, sequence, and dependency.

What is a project network?

A project network is a graph that shows the activities, duration, and interdependencies of tasks within your project.

What is a project schedule network diagram in project management?

A project schedule network diagram visualizes the sequential and logical relationship between tasks in a project setting. This visualization relies on the clear expression of the chronology of tasks and events.

Most often, a project network diagram is depicted as a chart with a series of boxes and arrows. This network diagram tool is used to map out the schedule and work sequence for the project, as well as track its progress through each stage — up to and including completion. Because it encompasses the large tasks that need to occur over the project’s duration, a network diagram is also useful in illustrating the scope of the project.

Benefits of the project management network diagram

A network diagram allows a project manager to track each element of a project and quickly share its status with others. Its other benefits include:

  • Visual representation of progress for stakeholders
  • Establishing project workflows
  • Tracking dependencies and potential bottlenecks

Research also shows that depicting data in a visual way can improve comprehension and enhance retention — meaning that a network diagram can boost performance and productivity while reducing stress among your team members.

Video preview

Types of project network diagrams: Arrow diagram and precedence diagram

There are two main types of network diagrams in project management: the arrow diagramming method (ADM), also known as “activity network diagram” or “activity on arrow”; and the precedence diagramming method (PDM), also known as “node network” or “activity on node.”

Arrow diagram method (ADM)

The ADM, or activity network diagram, uses arrows to represent activities associated with the project. It’s important to note that, due to the ADM’s limitations, it is no longer widely used in project management. However, it’s still useful to understand ADMs, so that you can recognize these diagrams if they arise in your work environment.

  • The tail of the arrow represents the start of the activity and the head represents the finish.
  • The length of the arrow typically denotes the duration of the activity.
  • Each arrow connects two boxes, known as “nodes.” The nodes are used to represent the start or end of an activity in a sequence. The starting node of an activity is sometimes called the “i-node,” with the final node of a sequence sometimes called the “j-node.”
  • The only relationship between the nodes and activity that an ADM chart can represent is “finish to start” or FS.

Occasionally, “dummy activities”—arrows that do not represent a direct relationship—need to be included in ADM network diagrams. In the diagram below, activity C can only occur once activities A and B are complete; in the network diagram, you’ve connected activity A to activity C. Perhaps we’re talking about tiling a floor (activity C): It can only begin once the concrete is poured (activity A) and the permits are obtained (activity B). Since activities A and B are not directly related—A doesn’t lead to B, and B doesn’t lead to A—you’ll need to draw a dummy activity between B and C to show that C is dependent on B being completed.An ADM chart also does not have a way to encapsulate lead and lag times without introducing new nodes and activities.


Precedence diagram method (PDM)

PDM network diagrams are frequently used in project management today and are a more efficient alternative to ADMs. In the precedence diagramming method for creating network diagrams, each box, or node, represents an activity—with the arrows representing relationships between the different activities. The arrows can therefore represent all four possible relationships:

  • “Finish to Start” (FS): When an activity cannot start before another activity finishes
  • “Start to Start” (SS): When two activities are able to start simultaneously
  • “Finish to Finish” (FF): When two tasks need to finish together
  • “Start to Finish” (SF): This is an uncommon dependency and only used when one activity cannot finish until another activity starts

In PDM, lead times and lag times can be written alongside the arrows. If a particular activity is going to require 10 days to elapse until the next activity can occur, for example, you can simply write “10 days” over the arrow representing the relationship between the connected nodes.
